Fully Automatic Robotic Single Column Palletizer for Boxes Unloading

Product Details

Model NO.:

SPCPAMD

Capacity:

10-120 Cases /Min Customized

Power:

21kw

Weight:

9200kg

Dimension:

14500*7000*3750mm

Transport Package:

Film Packing Or Wooden Case

Specification:

8000Kg

Trademark:

PEIYU

Origin:

China

Production Capacity:

500 Sets/Year

Highlight:

fully automatic robotic palletizer

single column palletizer for boxes

beverage unloading palletizer

Payment & Shipping Terms

Minimum Order Quantity

Price

100000

Robotic Palletizing System That Marshals First and Then Palletizer for Beverage Lines

Get Best Price

Robotic Palletizer Robotic Palletizing System Canned Palletizer for Pet Food Packaging Lines

Get Best Price

Customized Double-Lane Case Palletizer with Paper Separators for Bottled Water Line

Get Best Price

Gantry Palletizer Beverage Palletizer Customized for Beverage Line

Get Best Price

+86 13030636622

marketing@pyspc.com

Contact Now

Product Description

Fully Automatic Robotic Single Column Palletizer for Boxes Unloading

Product Description

The single-column palletizing machine is composed of an acceleration belt, a steering stacking roller, a case arrangement table, a column, a beam, a pallet divider and a roller conveyor, and it is suitable for stacking various packages such as carton, plastic case, shrink film package or other packaging pieces.

The workflow: the machine automatically stacks the cartons on the pallet layer by layer according to the pre-designed stack type. Under the combined action of single column lifting mechanical structure and pushing box structure, stacking reaches a specified height and the cartons stack is passed through the roller conveyor line moved to the forklift and transported to the warehouse for storage. This machine is controlled by PLC and touch screen, realizing high degree of automation, simple operation, easy to master, small floor space, high palletizing efficiency, low failure rate and convenient maintenance.

Technical Specifications

Operating Mode	Stacking layer by layer	Conveyor Height	750mm
Capacity	60 Cartons/min	Pallet Conveyor Height	500mm
Driven Type	Electric	Maximum Load Per Layer	200kg
Pallet Size	Standard Pallet (as demanded)	Maximum Load Per Pallet	1500Kg
Dimension	950060003700mm	Applicable Product	Carton, Plastic case, Shrink film packaging
Palletizing Storage	15 pallets	Total Power	22KW
Weight	8000kg	Transport Package	Film Packing or Wooden Case
