Name: Full Automatic Heat Shrink Film Packaging Machine with Stainless Steel Heating for 12,000 to 48,000 Bottles/Hour
Brand: Shanghai Peiyu Packaging Technology Co.,Ltd.
SKU: SPCSW.G1
Availability: InStock

Home > Products > Shrink Packer >

Full Automatic Heat Shrink Film Packaging Machine with Stainless Steel Heating for 12,000 to 48,000 Bottles/Hour

Full Automatic Heat Shrink Film Packaging Machine

Stainless Steel Heating Shrink Packer

12

Place of Origin:

China

Brand Name:

Peiyu

Certification:

CE,ISO9001:2008,High-tech enterprise

Model Number:

SPCSW.G1

Request A Quote

Product Details

Model NO.:

Customized

Automatic Grade:

Automatic

Driven Type:

Mechanical

Manner Of Packing:

Both Ends Open

Adjust Speed:

Electronic Speed Control

Type:

PE Shrink Film Machine

Heating Mode:

Stainless Steel Heating

Packaging Material:

Film

Capacity:

30-260 Cartons/Minute/Customized

Power:

380V 50Hz Customized

Applicable Container Size:

100g-3kg Customized

Equipment Model:

SPCSW.E2

Equipment Weight:

6000Kg

Operating Air Pressure:

0.5-0.7MPa

Air Consumption:

100L/min Max

Working Voltage:

380V AC 50HZ; 24V DC/AC

Input Power:

75KW

Equipment Size:

L=12444mm × W=2010mm × H=2295mm

Highlight:

Full Automatic Heat Shrink Film Packaging Machine

Stainless Steel Heating Shrink Packer

12

Payment & Shipping Terms

Minimum Order Quantity

Price

Individual quotation according to different requirements

Packaging Details

The packaging uses new, sturdy special packaging boxes or fixed frames, which are suitable for long-distance transportation, moisture-proof, rust-proof, shock-proof, and suitable for land and sea transportation and overall lifting.

Delivery Time

30-40 work days

Payment Terms

L/C,T/T

Supply Ability

300 pcs per month

marketing@pyspc.com

Contact Now

Product Description

Heat Shrink Film Packaging Machine for Water Production Line

Application Scope

This industrial-grade heat shrink packaging machine is designed for packaging glass bottles, PET bottles, and cans in water, beverage, beer, food, and pharmaceutical industries.

Production capacity range: 12,000 to 48,000 bottles/hour
Packaging speed: 30 to 260 packages per minute (depending on specifications)

Equipment Principle

The machine operates through a precise automated process:

Products are evenly distributed via entrance plate chain with bottle shortage detection
Arranged through gate/bottle pressing mechanism
Pushed to film winding belt by bottle pushing rod mechanism
Film roll passes through splicing mechanism for continuous operation
Final packaging enters heat shrinking furnace for perfect seal

Key Features

Compact structure with minimal footprint
User-friendly LCD touch screen control system
Comprehensive safety protection devices
Micro-vibration bottle separation for round bottles
Torque limit protection on push rod components

Technical Specifications

Parameter	Value
Model	SPCSW.E2
Production Capacity	30 packs/minute (round bottles)
Applicable Container Types	Cans, glass bottles, PET containers
Conveyor Belt Height	1050mm
Equipment Weight	Approx. 6000Kg
Operating Pressure	0.5-0.7MPa
Power Requirements	380V AC 50HZ; 24V DC/AC
Input Power	75KW

Component Configuration

Component	Brand
PLC	Inovance, China
Servo Motor & Control System	Inovance, China
Configuration Software	Ab Optix
Frequency Converter	Inovance, China
Proximity Switches	SICK or equivalent

Equipment Dimensions

L=12444mm * W=2010mm * H=2295mm

Ordering Information

Quotation validity: 1 month
Payment methods: T/T, L/C
Delivery time: 60 working days after deposit receipt
Customer provides product samples for factory testing

Quality Assurance

12-month equipment warranty (24 months for control system)
On-site support within 48 hours for critical issues
Lifetime technical support and spare parts availability
ISO9001 certified manufacturing
CE certified for European markets
