Name: Dual-Channel Automatic Shrink Wrapper Machine with Stainless Steel Heating and Electronic Speed Control for PE Shrink Film
Brand: Shanghai Peiyu Packaging Technology Co.,Ltd.
SKU: SPCSW.G1
Availability: InStock

Home > Products > Shrink Packer >

Dual-Channel Automatic Shrink Wrapper Machine with Stainless Steel Heating and Electronic Speed Control for PE Shrink Film

Stainless Steel Heating Shrink Wrapper Machine

Electronic Speed Control Shrink Packer

PE Shrink Film Heat Shrink Packaging Machine

Place of Origin:

China

Brand Name:

Peiyu

Certification:

CE,ISO9001:2008,High-tech enterprise

Model Number:

SPCSW.G1

Request A Quote

Dual-Channel Automatic Shrink Wrapper Machine with Stainless Steel Heating and Electronic Speed Control for PE Shrink Film

Product Details

Model NO.:

Customized

Automatic Grade:

Automatic

Driven Type:

Mechanical

Manner Of Packing:

Both Ends Open

Adjust Speed:

Electronic Speed Control

Type:

PE Shrink Film Machine

Heating Mode:

Stainless Steel Heating

Packaging Material:

Film

Capacity:

30-260 Cartons/Minute/Customized

Power:

380V 50Hz Customized

Applicable Container:

Pet/PE/PP Bottles, Glass Bottles, Cans

Applicable Container Size:

100g-3kg Customized

Production Capacity:

500 Sets/Year

Equipment Weight:

6000Kg

Operating Air Pressure:

0.5-0.7MPa

Highlight:

Stainless Steel Heating Shrink Wrapper Machine

Electronic Speed Control Shrink Packer

PE Shrink Film Heat Shrink Packaging Machine

Payment & Shipping Terms

Minimum Order Quantity

Price

Individual quotation according to different requirements

Packaging Details

The packaging uses new, sturdy special packaging boxes or fixed frames, which are suitable for long-distance transportation, moisture-proof, rust-proof, shock-proof, and suitable for land and sea transportation and overall lifting.

Delivery Time

30-40 work days

Payment Terms

L/C,T/T

Supply Ability

300 pcs per month

60 Packs Per Minute Automatic Shrink Wrapping Machine with 30-260 Cartons/Minute Capacity and 380V 50Hz Power

Get Best Price

Video

Single Double Layer Stacking Half Tray and Film Shrink Wrapper Packing Machine for 100g-3kg Containers

Get Best Price

Video

50 Packs Per Minute Automatic Shrink Packer with 30-260 Cartons/Minute Capacity for 100g-3kg Containers

Get Best Price

Video

Automatic Single Double Layer Stacking Half Tray Shrink Wrapping Machine with 30-260 Cartons/Minute Capacity

Get Best Price

+86 13030636622

marketing@pyspc.com

Contact Now

Product Description

Dual-Channel Shrink Wrapper Machine for Canned Carbonated Beverage Production Lines

Application Scope

This industrial-grade heat shrink packaging machine is designed for glass bottles, PET bottles, and cans in water, beverage, beer, food, and pharmaceutical industries. Production capacity ranges from 12,000 to 48,000 bottles/hour (30-260 packages/minute depending on specifications).

Shrink packer Heat shrink packer Dual Channel packaging Tray shrink wrapping Automatic shrink wrap PE Film Packaging

Equipment Principle

The machine evenly distributes products via entrance plate chain with bottle shortage detection. Products are arranged through gate mechanisms, pushed to film winding belts, and wrapped with film from rolls that pass through splicing and tensioning mechanisms before entering the heat shrinking furnace.

Key Features

Compact structure with small footprint
User-friendly LCD touch screen control system
Comprehensive safety protection devices
Micro-vibration bottle separation for round bottles
Torque limit protection on push rod components

Packaging Specifications

Film roll requirements: 78mm axis hole diameter, <650mm width, ≤400mm diameter. Special bottle types or packaging methods require engineer consultation.

Technical Specifications

Model	SPCSW.E2
Capacity	30 packs/minute (round bottles)
Compatible Containers	Cans, glass bottles, PET
Conveyor Height	1050mm
Weight	6000Kg
Power Requirements	380V AC 50HZ; 24V DC/AC
Power Consumption	75KW

Component Configuration

Component	Brand
PLC	Inovance, China
Servo System	Inovance, China
Control Software	Ab Optix
Frequency Converter	Inovance, China
Sensors	SICK or equivalent

Equipment Dimensions

12444mm (L) * 2010mm (W) * 2295mm (H)

Ordering Information

Quote validity: 1 month
Payment: T/T, L/C
Customer provides samples for factory trials
Delivery: 60 working days after deposit receipt

Quality Assurance

12-month warranty on equipment (24 months for control systems). Includes free spare parts and on-site support within 48 hours for warranty claims. Lifetime technical support available post-warranty.

Shipping

Industrial-grade packaging suitable for land/sea transport with moisture, rust, and shock protection.
