Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer

Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer

Wide Side Wrap Around Case Packer

Mechanical Stretch Carton Packer

No Pallet Wrapping Case Packing Machine

Place of Origin:

China

Brand Name:

Peiyu

Certification:

CE,ISO9001:2008,High-tech enterprise

Model Number:

SPCWM.NA1H

Contact Us
Request A Quote
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer
Product Details
Capacity:
20-100 Packs/Minute
Power:
380V 50Hz
Installed Power:
30KW
Operating Power:
20KW
Equipment Weight:
11000Kg
Operating Air Pressure:
6bar
Air Consumption:
160L/min Max
Working Voltage:
380V AC 50HZ; 24V DC/AC
Carton Length:
150mm-420mm
Carton Width:
130mm-350mm
Carton Height:
100mm-335mm
Product Diameter:
φ52mm-106mm
Product Height:
95mm-330mm
Equipment Size:
15850mm×4050mm×2150mm
Box Conveyor Elevation:
1350mm±30mm
Highlight:

Wide Side Wrap Around Case Packer

,

Mechanical Stretch Carton Packer

,

No Pallet Wrapping Case Packing Machine

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Individual quotation according to different requirements
Packaging Details
The packaging uses new, sturdy special packaging boxes or fixed frames, which are suitable for long-distance transportation, moisture-proof, rust-proof, shock-proof, and suitable for land and sea transportation and overall lifting.
Delivery Time
10-20 workdays
Payment Terms
L/C,T/T
Supply Ability
300 pcs per month
RELATED PRODUCTS
Good price 80 Cases Per Minute Glass Bottle Wrap Around Case Packer for Juice Production Line online Video

80 Cases Per Minute Glass Bottle Wrap Around Case Packer for Juice Production Line

Get Best Price
Good price Pneumatic CE ISO Certified Wrap Around Case Packer with Schneider Electrics for Food and Beverage Packaging online Video

Pneumatic CE ISO Certified Wrap Around Case Packer with Schneider Electrics for Food and Beverage Packaging

Get Best Price
Good price 50 Packs Per Minute 380V 50Hz Automatic Wrapped Packaging Machine for E-Commerce Packaging online Video

50 Packs Per Minute 380V 50Hz Automatic Wrapped Packaging Machine for E-Commerce Packaging

Get Best Price
Good price Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer online Video

Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer

Get Best Price
Contact Us
+86 13030636622
marketing@pyspc.com
Contact Now
Product Description
Low Speed Wide Side Wrap Around Case Packer Machine Carton Packer
Product Overview
This wrap around case packer is designed for secondary packaging of PET bottles, glass bottles, or metal cans, serving as an efficient alternative to traditional cartoning machines and their ancillary equipment.
Key Features
  • Applicable bottle types: square bottles, flat bottles, round bottles
  • Packaging capacity: 35-100 packs per minute (depending on specifications)
  • Also known as: Carton Packer, Case Packer, Wrap Around Packer, and various other industry terms
Main Components Configuration
Component Brand
PLC Inovance, China
Servo motor and control system Inovance, China
Upper configuration software Ab Optix
Frequency converter Inovance, China
Proximity electronic switch SICK or equivalent brand
Air switch Equivalent brand
Technical Specifications
Parameter Value
Production capacity 80 packs/minute (varies by bottle type)
Carton dimensions (L*W*H) 150-420mm * 130-350mm * 100-335mm
Product height range 95mm-330mm
Equipment dimensions (L*W*H) 15850mm * 4050mm * 2150mm
Equipment weight 11000Kg
Operating air pressure 6bar
Power requirements 380V AC 50HZ; 24V DC/AC
Carton Folding Process
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 0
Inner flap forming process flow
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 1
Outer tongue forming process flow
Equipment Components & Process Flow
The machine consists of multiple components including rack, bottle feeding conveyor, pressure control module, product grouping system, cardboard handling system, forming sections, and electrical controls.
Servo Mechanism Distribution
Mechanism Number of Servos
Upper forming 2
Lower forming 2
Folding on both sides 4
Top capping 1
Forming transition zone 1
Product Images
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 2
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 3
Manufacturer Information
Peiyu Enterprise owns multiple manufacturing companies in China, providing complete intelligent equipment solutions for liquid and solid product packaging. With extensive experience and advanced manufacturing facilities, we serve global clients across beverage, dairy, pharmaceutical, and other industries.
Certifications
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 4
Production Facility
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 5
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 6
Electrical Components
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 7
Client Portfolio
Wide Side Mechanical Stretch No Pallet Wrapping Wrap Around Case Packer Carton Packer 8
